The MOBL (RGBW) Backlight Series is designed for maximum output and includes four wavelengths. Each wavelength is independent and can be tuned individually, allowing for the light to output just about any color imaginable. Proper heat dissipation is achieved using the side extrusion. The 45 mm extrusion makes mounting the light easy when using drop-in T-nuts. The MOBL (RGBW) Backlight Kit includes an MOBL RGBW backlight, external driver and reverse-key jumper cable. This product comes in the following sizes: 150 mm x 150 mm, 300 mm x 150 mm, and 300 mm x 300 mm.

The ODAL Area Light Series of spot lights is designed for OverDrive^™ strobing and produces maximum light output. NPN or PNP trigger signals input can be used to control the pulse of the light. The intensity of the light can be controlled via 1-10VDC analog signal line. Proper heat dissipation is achieved using the side extrusion and backplate. The 45 mm extrusion makes mounting the light easy when using drop-in T-nuts. The AL Area Light has a built-in driver. No external driver is required. Standard sizes are: 150×150, 300×150, 300×300 – additional sizes are available upon request.

The ODLW300 Series features a 100% waterproof stainless-steel enclosure specially designed for the food industry and washdown environments where water and harsh detergents are present. The integrated OverDrive^™ driver allows for a maximum strobe rate of 5000 strobes per second. NPN or PNP trigger signal input can be used to control the pulse of the light. The intensity of the light can be controlled via 1-10VDC analog signal line or the onboard manual potentiometer. Daisy-chain up to six ODLW300 lights together.

The modular design of the ODLX150 linear light, part of the Direct Connect Linear Light Series, offers integrated light-to-light connectors, eliminating the need for cable connectors to string lights together. The light operates in OverDrive^™ strobe-only mode. This innovative design requires a power connection to the first light but eliminates the need for jumper cables to pass power through to the next, enabling tailored-length solutions in increments of 150 mm. Direct connect up to sixteen ODLX150 together.

Product Advantages

• Built-In Driver: This light features a built-in constant current driver, no external driver is needed.
• IEC Safety: This light is in compliance with IEC 62471 standards and has been tested in our in house IEC safety laboratory.
• SafeStrobe^™ Technology: This unique technology applies safe working parameters to ensure the LEDs are not damaged by driving them beyond their limits.
• Best Lead Time: Most of our standard products ship within three business days.
• Best Warranty: 10-year warranty on most of our products.

The ODR130 EZ Mount Ring Light Series is an all-around durable light that also features an OverDrive^™ strobe driver with NPN or PNP signal trigger inputs. Its simple plug-and-play 5-pin M12 connector is easy to use. The 10%-100% intensity control gives users full control over light output. A standard 42 mm inner hole diameter allows for use with nearly all camera systems with available step-up and step-down conversion kit adapters.

The ODR130-16 EZ Mount Ring Light Series is an all-around durable light that also features an OverDrive^™ driver with NPN or PNP signal options and provides double the light output as the standard ODR130. Its simple plug-and-play 5-pin M12 connector is easy to use. The 10%-100% intensity control gives users full control over light output. A standard 42 mm inner hole diameter allows for use with nearly all camera systems with available step-up and step-down conversion kit adapters.

The ODRD80 EZ Mount Ring Light Series features a factory-installed diffused lens cover and is an all-around durable light. It features an OverDrive^™ strobe driver with NPN or PNP signal trigger inputs. Its simple plug-and-play 5-pin M12 connector is easy to use. The 10%-100% intensity control gives users full control over light output. A standard 42 mm inner hole diameter allows for use with nearly all camera systems with available step-up and step-down conversion kit adapters.

The ODRL200 Large Ring Light Series is designed to produce a homogeneous, uniform light pattern for larger applications and longer working distances. This light operates in OverDrive^™ strobe mode. The ODRL200 runs on an industry-standard 24VDC. The 1-10VDC analog control line gives the user total control over intensity. Proper heat dissipation is achieved using the side extrusion. The 45 mm extrusion makes mounting the light easy when using drop-in T-nuts. The 5-pin M12 connector makes wiring to the light simple.
