Features:
● Reversible Type-C port connection
● Sony STARVIS and Pregius CMOS sensors
● With trigger and I/O
● Single-board cameras
| Product code | Megapixel | Resolution | FPS | Format | Sensor | Trigger | I/Os | Sensor type | Shutter |
|---|---|---|---|---|---|---|---|---|---|
| DFK 37BUX287 | 0.4 MP | 720×540 | 539 | 1/2.9 inch | IMX287 | ✔ | ✔ | CMOS Pregius | global |
| DFK 37BUX273 | 1.6 MP | 1,440×1,080 | 238 | 1/2.9 inch | IMX273 | ✔ | ✔ | CMOS Pregius | global |
| DFK 37BUX462 | 2.1 MP | 1,920×1,080 | 143 | 1/2.8 inch | IMX462 | ✔ | ✔ | CMOS STARVIS | rolling |
| DFK 37BUX290 | 2.1 MP | 1,920×1,080 | 143 | 1/2.8 inch | IMX290 | ✔ | ✔ | CMOS STARVIS | rolling |
| DFK 37BUX252 | 3.1 MP | 2,048×1,536 | 119 | 1/1.8 inch | IMX252 | ✔ | ✔ | CMOS Pregius | global |
| DFK 37BUX265 | 3.1 MP | 2,048×1,536 | 60 | 1/1.8 inch | IMX265 | ✔ | ✔ | CMOS Pregius | global |
| DFK 37BUX250 | 5 MP | 2,448×2,048 | 75 | 2/3 inch | IMX250 | ✔ | ✔ | CMOS Pregius | global |
| DFK 37BUX264 | 5 MP | 2,448×2,048 | 38 | 2/3 inch | IMX264 | ✔ | ✔ | CMOS Pregius | global |
| DFK 37BUX178 | 6.3 MP | 3,072×2,048 | 60 | 1/1.8 inch | IMX178 | ✔ | ✔ | CMOS STARVIS | rolling |
| DFK 37BUX226 | 12 MP | 4,000×3,000 | 30 | 1/1.7 inch | IMX226 | ✔ | ✔ | CMOS STARVIS | rolling |
Having superb image quality, the all-new IC-X25B-CL provides the best performance-for-value ratio of all of ISVI’s new compact cameras. Using its Full Configuration Camera Link interface it achieves a frame rate of 30Hz. Its compact size and wide selection of standard lens mounts makes it a popular choice for users requiring a high-resolution camera but do not need the high frame rates of our CXP cameras.
Key Features:
The FXO stands for excellent image quality. The fast 10GigE interface is an extremely economical interface and at the same time offers excellent conditions for use in larger networks. The large framebuffer and packet resend ensure reliable top frame rates. Up to 100 m cable length is supported by the modern network technology of the FXO.
An excellent, low-noise image with high dynamics is complemented by a comprehensive feature set. The Sony Pregius S sensors used are characterized by high light sensitivity and best homogeneity. Signal voltages, temperature resistance, I/O control, integrated strobe controller and firmware features are aimed at applications in industrial automation.
Technical highlights:
The successful EXO series is the shining basis of the EXO Tracer. The Tracer comes with identical camera features and additionally with a fully functional lens control (focus, zoom, aperture). Lens mount is a Micro Four Thirds (MFT) mount, covering all electric connections. Due to the size of the MFT Bayonet, the Tracer is a bit larger than the original EXO in dimensions. Still, the excellent thermal concept of the EXO qualifies for a operating temperature of up to 60°C.
All MFT lenses feature a specific beam geometry on the sensor side of the lens, which works in perfect harmony to sensors between 2/3″ and 1.2″. A nearly perfect flatfield is the compelling result. Together with up to 72dB dynamic range and up to 20 MP resolution, the Tracer delivers excellent image quality with its highly sensitive sensors.
The lens properties are integrated into the camera’s GenICam 3.0 tree, any GenICam-driven software is immediately able to use lens control without additional drivers. Same thing is valid for the integrated LED strobe control: All items adjustable via GenICam properties. This permits effortless and quick machine vision integration.
Tests at SVS-Vistek showed a surprising high repeatability of the lenses, even after 1 Mio focus cycles. Focus and zoom times are similar to what you know from lenses in photography.
The ECO-series is compelling by virtue of its extremely compact design (38 x 38 x 33 mm) and offers the best value for money. Resolution ranging from VGA to 5 MegaPixel combined with high frame rates. The ECO is small, robust, fit for the factory floor, manufactured with precision, safe to connect, offers an LED controller, is PLC ready and reliable.
